2in AIN On Sapphire Wafer Sapphire Single Or Double Side Polished AlN-T-C-U-C50
2 Inch Thick Film (2,3)Um AIN On Sapphire Wafer,SSP,XRD FWHM Of(002)≤100arcsec(102) ≤550arcsec UV Disinfection LED Chip
Overview
The electricity savings of using LEDs instead of traditional cold-cathode fluorescent lamps (CCFLs) can reach 70%. Also, unlike CCFLs, AlN LEDs do not contain mercury, allowing more environmentally friendly disposal. AlN LEDs can also be used for non-line-of-sight communications.
Currently, the newest-generation AlN-on-sapphire LEDs technology is approaching 50,000 hours of life, compared with just 10,000 hours for existing AlN-on-sapphire LEDs. The cost saving will only increase with time, adds the firm.
Specification
| Item |
AlN-T-C-U-C50 |
| Dimensions |
φ50.8 mm±0.1 mm,OF(1-100),Al Face,Locating Edge 16.0± 1.0 mm |
| Substrate |
Sapphire(Single or Double Side Polished) |
| Thickness |
1~5μm |
| Orientation |
C-plane (0001)±1o
|
| Conduction Type |
Semi-Insulating |
| Crystalline Quality |
Thickness |
XRD FWHM of(002) |
XRD FWHM of(102) |
| |
[1,2)μm |
≤80arcsec |
≤650arcsec |
| |
[2,3)μm |
≤100arcsec |
≤550arcsec |
| |
[3,4)μm |
≤120arcsec |
≤450arcsec |
| |
[4,5)μm |
≤160arcsec |
≤400arcsec |
| Edge Exclusion Zone |
<2mm
|
| Surface Roughness |
Ra<1.5nm(10*10μm) |
| Package |
Vacuum packing in a class 10000 clean room environment,in cassettes of 25pcs or single wafer containers. |
About Us
We specialize in processing a variety of materials into wafers, substrates and customized optical glass parts.components widely used in electronics, optics, opto electronics and many other fields. We also have been working closely with many domestic and oversea universities, research institutions and companies, provide customized products and services for their R&D projects. It's our vision to maintaining a good relationship of cooperation with our all customers by our good reputations.
FAQ
Q: Are you trading company or manufacturer ?
We are factory.
Q: How long is your delivery time?
Generally it is 3-5 days if the goods are in stock.
or it is 7-10 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
Payment <=5000USD, 100% in advance.
Paymen >=5000USD, 80% T/T in advance , balance before shippment.
