A-Plane±0.2o Patterned Sapphire Substrates BOW≤-8~0μM Back Surface Roughness 0.8~1.2μm
2inch Patterned Sapphire Substrates,LED Chip,Substrate Material
The regular patterns created on the sapphire substrate counteracts the effect of the total internal reflection at the GaN/sapphire interface. And, the enhancement in the internal quantum efficiency benefits from the reduction of threading dislocations by possible lateral growth of GaN epilayer on the patterned sapphire substrate.
| 2inch Patterned sapphire substrate |
| Item | Al2O3 |
|
| Dimension | 50.80±0.10mm |
| Thickness | 430±10μm |
| Flat edge width | 16±1.0mm |
| Flat edge angle | A-plane±0.2o |
| TTV | ≤5μm |
| BOW | ≤-8~0μm |
| Front Surface Roughness | ≤0.25nm |
| Back Surface Roughness | 0.8~1.2μm |
| Edge | Round |
| Laser making | back |
